Mini-DIN 8 to RGB SCART individually fully shielded 75Ω Coaxial Pro "Mini-Coax" cable with isolated grounds.
Compatibility:
- Home Arcade System (HAS) “Supergun” V4.0, V4.1 and V4.2.
- RGB modified consoles utilizing a Mini-DIN 8 port for AV output.
- Such as: Atari 2600, NES, Game Gear, Philips CDi, 3DO and others.
- The port must be installed with an inset depth not to exceed 6 mm and a shell opening diameter no less than 11 mm.
- Stereo audio must be wired to pins 1 and 2 on the Mini-DIN 8 port in accordance with this diagram.
Not Compatible With:
- RGB mods that require a separate 3.5mm TRS audio cable.
- XRGB-mini Framemeister.
- JP21 (RGB-21, EIAJ TTC-003) devices.
Features:
- Wired to the Euro SCART standard (not JP21).
Miniature Coaxial ("Mini-Coax") is a benchmark professional-grade cable developed exclusively for Retro Access to deliver the highest possible analog audio and video quality out of your retro gaming systems.
Mini-Coax maintains a true 75Ω characteristic impedance, with each signal line featuring a polyethylene dielectric for precision impedance control and full coverage individually shielded copper spiral wrap with isolated grounds. Thicker and higher quality, its fully double-shielded construction blocks crosstalk, rejects external interference, and meets professional studio and broadcast-grade standards. It is the only RGB cable of its kind.
- Prevents signal reflections, ringing and ghosting for uncompromised video fidelity.
- Virtually eliminates the color bleed crosstalk and audio buzzing experienced in lower quality cables.
- Maintains brightness and color accuracy, providing crisp RGB, especially over lengths beyond 6 ft (1.8 m).
Visit the Knowledge Center to learn more about Mini-Coax.
