Super NES (NTSC), Nintendo 64 (RGB modded) to RGB SCART individually fully shielded 75Ω Coaxial Pro "Mini-Coax" cable with isolated grounds.
The Retro Access exclusive 3-position MultiSync selector switch supports three sync modes: Composite Sync (CS), Sync on Luma (Y), and Sync on Composite Video (CV). This opens up flexibility for compatibility across a wide variety consoles, mods, switches and displays, all in a single cable.
Compatibility:
- Super NES (NTSC-U, USA)
- Super Famicom (NTSC-J, Japan)
- AV Famicom with RGB Mod
- New-Style Super NES (NTSC-U, USA) with RGB Mod
- Super Famicom Jr. (NTSC-J, Japan) with RGB Mod
- Nintendo 64 with RGB Mod
Not Compatible With:
- Super NES (PAL, Europe)
- GameCube
For Use With:
- SCART televisions and RGB Mux Mods.
- RetroTINK 5X-Pro, 4K CE, 4K Pro.
- OSSC (Open Source Scan Converter).
- XRGB-mini Framemeister (Adapter required, not provided).
- Morph 4k with Analog Bridge Expansion Module.
- Switches including Gscartsw and SVS.
Features:
- Three Sync Modes: Composite Sync (CSync, “CS”), Sync on Luma (“Y”), Sync on Composite Video (CVBS, “CV”).
- CSync Mode Only: Resistor attenuated for 75Ω level inputs on consumer devices.
- Genuine Kemet premium 220 µF Tantalum AC coupling capacitors within the console connector provide clean, precise RGBS signals at the source, preventing unwanted DC bias along the cable, preserving accurate color, contrast and brightness.
Wired in accordance with the SCART (EuroSCART) standard. This cable is incompatible with Japan RGB 21-Pin (JP21) devices.
Miniature Coaxial ("Mini-Coax") is a benchmark professional-grade cable developed exclusively for Retro Access to deliver the highest possible analog audio and video quality out of your retro gaming systems.
Mini-Coax maintains a true 75Ω characteristic impedance, with each signal line featuring a polyethylene dielectric for precision impedance control and full coverage individually shielded copper spiral wrap with isolated grounds. Thicker and higher quality, its fully double-shielded construction blocks crosstalk, rejects external interference, and meets professional studio and broadcast-grade standards. It is the only RGB cable of its kind.
- Prevents signal reflections, ringing and ghosting for uncompromised video fidelity.
- Virtually eliminates the color bleed crosstalk and audio buzzing experienced in lower quality cables.
- Maintains brightness and color accuracy, providing crisp RGB, especially over lengths beyond 6 ft (1.8 m).
Visit the Knowledge Center to learn more about Mini-Coax.
