MiSTer FPGA, MiSTER Pi, SuperStation One (DE-15 D-Sub) to RGB SCART to RGB SCART ultra-flexible 100% shielded Fortraflex 6 ft (1.8 m) cable.
Compatibility:
- MiSTer FPGA
- MiSTER Pi
- SuperStation One
- Output of HD15 Splitters and Switches.
Not Compatible With:
- SCART sources such as the output of a SCART switch or splitter.
- Analogue Nt Mini (See: Analogue RGB SCART Cable).
- Devices which output VGA (RGBHV) signals such as PCs.
For Use With:
- SCART televisions and RGB Mux Mods.
- RetroTINK 5X-Pro, 4K CE, 4K Pro.
- OSSC (Open Source Scan Converter).
- XRGB-mini Framemeister (Adapter required, not provided).
- Morph 4k with Analog Bridge Expansion Module.
- Switches including Gscartsw and SVS.
Features:
- Composite Sync (CSync) with attenuating resistor safely conditions the sync signal for 75Ω level inputs on consumer devices. The HD15 source must be configured for TTL (5V) level on pin 13.
- Stereo audio jack with included aux cable.
Wired in accordance with the SCART (EuroSCART) standard. This cable is incompatible with Japan RGB 21-Pin (JP21) devices.
Fortraflex is a premium-grade, ultra flexible, and highly durable cable manufactured exclusively for Retro Access. Each signal line is 100% shielded with robust copper wrap to prevent signal degradation and crosstalk, maintaining clean analog video and suppressing unwanted audio buzz.
Built to a higher standard, Fortraflex features significantly thicker and denser shielding than other RGB cables. The soft outer jacket, also used in stage mic cables and official wired game controllers, ensures excellent flexibility and ease of movement.
Visit the Knowledge Center to learn more about Fortraflex.
